  • Teranex Mini convertitore da 12G-SDI a quad SDI con 4 uscite 3G-SDI
  • CONVNTRM/DB/SDIQD_BLACKMAGIC_Teranex Mini convertitore da 12G-SDI a quad SDI con 4 uscite 3G-SDI
  • CONVNTRM/DB/SDIQD_BLACKMAGIC_Teranex Mini convertitore da 12G-SDI a quad SDI con 4 uscite 3G-SDI
  • CONVNTRM/DB/SDIQD_BLACKMAGIC_Teranex Mini convertitore da 12G-SDI a quad SDI con 4 uscite 3G-SDI

Teranex mini converter 12G-SDI to Quad SDI with 4 3G-SDI outputs

We adhere to the OSS system and the VAT amount is calculated per individual country of destination of the goods. The exact value will be calculated at checkout.

 485,00  591,70 vat incl.

Aderiamo al sistema OSS e l'importo IVA è calcolato per singolo paese di destinazione della merce. Il valore preciso verrà calcolato in fase di checkout.
Information est omnia

In Stock

3 years warranty

blank Product Code / EAN: 9338716003499 SKU CONVNTRM/DB/SDIQD Category
Blackmagic official partner
Blackmagic official warranty

The Teranex mini converter 12G-SDI to Quad SDI with 4 3G-SDI outputs converts 12G-SDI signals to quad link SDI, making the latest generation 12G-SDI equipment compatible with Ultra HD quad link systems.

SECURE CHECK OUT

Related videos
Specifications
The Teranex mini converter 12G-SDI to Quad SDI with 4 3G-SDI outputs converts 12G-SDI signals to quad link SDI, making the latest generation 12G-SDI equipment compatible with Ultra HD quad link systems. It separates and distributes the Ultra HD SDI signal to the four HD SDI outputs, allowing you to create video walls with common HD displays. It includes a 12G-SDI loop output and is compatible with 3G-SDI level A and B systems.
Weight 580 g
Dimensions 14 x 17 x 4,4 cm
Input 1 x 12G-SDI SD/HD/2K/4K with automatic switching
Output 4 x 3G-SDI
1 x 12G-SDI di loop
Standard Standard video SD
525i59.94 NTSC, 625i50 PAL
Standard video HD
720p50, 720p59.94, 720p60
1080i50, 1080i59.94, 1080i60
1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60
1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30
Standard video 2K
2Kp23.98 DCI, 2Kp24 DCI, 2Kp25 DCI
2KPsF23.98 DCI, 2KPsF24 DCI, 2KPsF25 DCI
Standard video Ultra HD
2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p60
Standard video 4K
4Kp23.98 DCI, 4Kp24 DCI, 4Kp25 DCI
Consumption 16 W
Power supply 48 VDC PoE+
