Blackmagic Ultimatte 12 8K 12G-SDI high-performance broadcast video processor

We adhere to the OSS system and the VAT amount is calculated per individual country of destination of the goods. The exact value will be calculated at checkout.

 6.198,00  7.561,56 vat incl.

Aderiamo al sistema OSS e l'importo IVA è calcolato per singolo paese di destinazione della merce. Il valore preciso verrà calcolato in fase di checkout.
Information est omnia

In Stock

Shipped within 4-7 days
blank Product Code / EAN: 9338716006865 SKU ULTMKEY12/D/8K Category
Blackmagic official partner
Blackmagic official warranty

Blackmagic Ultimatte 12 8K 12G-SDI high-performance broadcast video processor is an advanced real-time compositing processor designed to combine live video with next-generation broadcast graphics, virtual sets, and more.

SECURE CHECK OUT

Related videos
Specifications
Blackmagic Ultimatte 12 8K 12G-SDI high-performance broadcast video processor is an advanced real-time compositing processor designed to combine live video with next-generation broadcast graphics, virtual sets, and more. It offers advanced algorithms and colour science, contour processing and colour separation, colour fidelity and contamination correction simply flawless. The high-performance Quad Link 12G-SDI design allows you to work in HD, Ultra HD and even 8K with sub-pixel processing for extraordinary results.

All Ultimatte 12 models incorporate the same formidable image processing algorithms and immense colour space, ensuring compositions of the same quality. Mattes are automatically generated internally to process different parts of the image separately according to colour. It takes meticulous care of contours to retain every detail, e.g. hair, and ensures smooth transitions between colours or other objects in the scene. The new sub-pixel processing delivers unparalleled quality and sharpness.

In live production, speed is everything. It offers single-touch compositing technology that analyses the scene and automatically sets more than 100 parameters to achieve perfect keys without difficulty. When the set is well lit and the white balance of the cameras optimal, simply activate Ultimatte’s automatic key and let it do the work for you. Each model also includes background correction to compensate for unevenly lit blue or green screens. Single-touch keys are significantly faster and guarantee accurate results with minimal effort, giving operators the freedom to concentrate on shooting.

It also offers advanced processing for the halo effect, contours and transitions, and to eliminate the background without affecting other colours. It accurately retains and reproduces colours impossible with other keyers, even the bright yellow of a green screen dress! Ultimatte 12 8K is so advanced that it isolates and treats distinct areas of the image separately, at the same time ensuring smooth transitions between them. Compositing quality is excellent and the final look photorealistic, sharp images with brilliant colours.

Advanced halo effect algorithms cleverly remove green contamination and other imperfections, creating realistic virtual environments. It automatically samples colours, creates accurate masks for walls, floors and other parts of the image, and applies the necessary correction. Shadows are properly mapped and composited onto the new background, contamination removed, and transparent objects treated to perfection!

The Ultimatte 12 4K and Ultimatte 12 8K boast 12G-SDI connections to work with current HD and future Ultra HD and 8K video formats. The 12G-SDI admits Ultra HD at high frame rates via a single BNC connection and connects to the HD equipment you already own. Ultimatte 12 4K is compatible with all SD, HD, 3G, 6G, and 12G-SDI devices, and supports all HD and Ultra HD formats up to 2160p60. Ultimatte 12 8K is equipped with Quad Link 12G-SDI for all video formats up to 4320p60 8K. So you can take advantage of the Ultimatte 12 with HD cameras right away and be ready to switch to Ultra HD or 8K at any time.
Welcome wallet with QR code to download the software included.

Weight 8,68 kg
Dimensions 48,2 x 33,8 x 8,4 cm
Input 32 x SDI
1 x BNC In
1 x Tri-Sync or Black Burst
1 x USB-C 3.0
Output 20 x SDI
20 x SD/HD/Ultra HD/ 8K with reclocking
1 x BNC Out
Standard Standard video SD
525i59.94 NTSC, 625i50 PAL
Standard video HD
720p50, 720p59.94, 720p60
1080i50, 1080i59.94, 1080i60
1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60
1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30
Standard video Ultra HD
2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p60
Standard video 8K
4320p23.98, 4320p24, 4320p25, 4320p29.97, 4320p30, 4320p50, 4320p59.94, 4320p60
Consumption 218 W
Power supply 2 x internal sources 100-240V AC, 50/60Hz
